UNUSED GLATT CMi 400 POWDER TOTE BLENDING SYSTEM

1 UNUSED GLATT STAINLESS STEEL MODEL CMi 400 STAINLESS STEEL COLUMN POWDER TOTE BLENDING SYSTEM.

Includes the following equipment:

·         CMi Blending column with lifting carriage.

·         CSi 100 Litre (600 x 600 mm), container IBC 21

·         CSi 200 Litre (800 x 800 mm), container IBC 24

·         CSi 400 Litre (800 x 800 mm), container IBC 27

·         Li 300, Lifting device for tablet press charging 30

GENERAL TECHNICAL DATA:

·         Pay load (product plus container IBC): 420 kg

·         Product load: 260 kg

·         Static load: 1400 kg

·         Optimum filling ratio of containers: 60 – 80 %

·         Height of blending envelope: approx. 2472 mm

·         Blending speed: 4 to 20 rpm

·         Blending time: 1 to 99 min

·         Lifting/lowering – hydraulic

·         Electrics: 3/60/600 volts

CONTROLS

·         EX-design: NON-EX design

·          Compressed air consumption: max. 1 Nm³/h

·         Flow pressure: 6 bar(g)

·         Compressed air quality: free of oil, water and particles

·         residual humidity water < 5.5 g/m³

·         fine filtered < 0.1 μm

·         residual oil content < 1.0 mg/m³

MATERIALS/SURFACE

·         External metal parts: stainless steel AISI 304/1.4301

·         Surface: ground and passivated

·         Surface roughness: Ra ≤ 1.2 μm

·         Load bearing core of the column: painted carbon steel St 52-3 (ST37) and sheathed with 304 stainless steel AISI

·         External non-metal parts: pharmaceutical grade synthetic materials

·         Sheathing: 2B rolled finish

·         Welded parts: Surface: ground and passivated

·         Surface roughness: Ra ≤ 1.2 μm

·         Load bearing welds: Surface: smoothed, all other welds ground flush

·         Approximate dimensions and weights: CMi: Height: 4500 to 4950 mm.

NOTES:

• EQUIPMENT STILL IN ORIGINAL OEM CRATING
• DQ, IQ/OQ INCLUDED
• MANUALS AND DRAWINGS
• CSA CERTIFIED
• LOCATED IN ONTARIO, CANADA
• PRICE PAID IN 2023: USD $245,000.
